The Underfloor Heating & Fan Coil Smart Thermostat is a versatile and user-friendly device designed to control air to water heat pump systems. Featuring a sleek and responsive touchscreen interface, this intelligent touch screen thermostat offers effortless temperature adjustments and remote control capabilities. Designed to be compatible with both water based underfloor heating and ceiling heating and cooling systems, this remote control smart thermostat offers versatility for various heating methods. It seamlessly integrates into existing setups without the need for complex installation procedures. |
Item Number | FT-66 |
Display | Black or White LCD |
Thermostat Dimension | 86*86*16 |
Material | Anti-flame ABS+PCS(ROHS certificated) |
Power Input | 230VAC,50/60HZ |
Load Current | 230V/3A |
Set Temp Range | 5~35℃ |
Display Temp | 0~99℃ |
Ambient Temp | 0~50℃ |
Floor Temp | 0~80℃ |
Relative Humidity | 85% |
Sensor Type | NTC 3950 10K |
Accuracy | ± 1℃ |
Modes | Manual /schedule/eco |
External Sensor | Yes (floor sensor) |
Floor Protection | yes |
Over Heat Protection | yes |
Application | Floor Heating, Fan Coil Control |
Emergency heating | yes |
Programmable/Schedule | yes |
Interaction Method | Touch button |
Language | English |
App | Tuya Smart, Smart Life (OPTIONAL) |
Certification | CE (RED/ECM/LVD) ,Rohs |
OEM levels | 1. Customized logo and package 2. Customized software (change to customer's user interface and control logic) 3. Customized hardware(change the PCB and schematic based on the request) |
Q1: Are you a manufacturer or trading company?
We are professional OEM/ODM thermostat manufacturer since 2003 based in Xiamen, Fujian provice, CHina.
Q2: What is your MOQ for batch order?
50 PCS
Q3: What is your stand lead time?
Samples : 3-5 workding days, Batch: 30-40 days
Q4: What certification do you have for your products?
CE/ROHS, FCC,UKCA, REACH(according to request)
Q5: What is your product warranty ?
1 year
Q6: How is the logo print and customized package?
We accept normally 1 color logo print, and customized CMYK printed box.
Q7: Do you have free spares for each order?
We don't have free spares but have free reparing or replacement policy , the qualify rate is 99.5%.
Q8: What is your advantage?
We have the largest manufacturing plant, full manufacturing lines, intact QC/QA systems, concentrated thermostat OEM&ODM service
Q9: What is your main market?
Whole Europe/ME/ Asia/Latin America/ US /Canada
